LPC Series

ID CLAMP COUPLER (LPC SERIES)

ID Clamp Coupler (LPC Series) provides leak-proof and secure connections by clamping and sealing the internal pipe diameter. Since it is specially meant for continuous use in connect and disconnect operations, especially in close-quater environments like heat exchangers, radiators, and fin coils, the coupler has a simple lever operation for quick lock-up and release
Its multi-stage sealing system offers secure grip on interior and exterior surfaces and is more appropriate for pressure, leak, and vacuum testing over low and high-pressure ranges. LPC Series offers flexibility, convenience, and reliability for abusive industrial uses.

Product Features

  • Designed to grip and seal the inner diameter of pipes effectively.
  • Ideal for continuous connect and disconnect operations.
  • Suitable for use in tight spaces such as heat exchangers, radiators, and fin coils.
  • Simple lever mechanism allows for easy locking and unlocking.
  • Multi-stage sealing ensures a secure grip on the inner diameter and a face seal for the outer diameter, enabling leak-free testing.
  • Compatible with both low and high-pressure applications.
  • Versatile usage for pressure, leak, and vacuum testing.
Model PIPE OD (mm) PIPE OD (Inches)
LPC 4764.763/16"
LPC 6006.00-
LPC 6356.351/4"
LPC 8008.005/16"
LPC 9529.523/8"
LPC 127012.701/2"
LPC 158715.875/8"
Specification Details
MOCAlloy, Brass, Stainless Steel
Thread Size1/4", 3/8", 1/2"
Working Pressure30 kg/cm²
Pressure Resistance40 kg/cm²
Suitable FluidR134a, R22, R407, R410a
Seals MaterialHNBR, FKM, NBR, CR
SL. NO. PARTICULARS MOC QTY
1Lock NutStainless Steel1
2Adjusting NutStainless Steel1
3Collet Spacer-IStainless Steel1
4Collet Spacer-IIStainless Steel1
5ColletEN-472
6Collet Spacer-IIIStainless Steel1
7Seal SpacerStainless Steel1
8SealFKM2
9StudStainless Steel1
10Face SealNBR1
11SliderAlloy Brass1
12Housing 'O' RingFKM1
13Latch SpacerStainless Steel1
14HousingAlloy Brass1
15Latch ScrewStainless Steel2
16LatchStainless Steel1
